APECS 300
Shingles/Tiles - Flat Lock Panel
Uses
- WALL / SOFFIT / ROOF (at 22 degree pitch)
Features & Benefits
Technical Specifications
Available in
| Aluminium PVDF coated | Zinc | Copper | |
|---|---|---|---|
| Thickness | Min. 0.7mm | Min. 0.7mm | Min. 0.6mm |
| Panel length | Please consult us at design stage | Please consult us at design stage | Please consult us at design stage |
| Panel width | Custom size and shape available upon request | Custom size and shape available upon request | Custom size and shape available upon request |
| Directions | 22 degrees | 22 degrees | 22 degrees |
System build up
| Wall structure | Must consist of continuous wall studs or top hats at max. 600mm spacing. |
| Direct support | Plywood 17mm structural to AS 2269 or trapezoidal substructure, others available upon request. |
| Underlay | Membrane |
| Fixings | Stainless steel flat lock clips |
Fully designed, build up system
Fully supported cladding system including plywood, membrane, metal and fixings, complete with all flashings, trims and waterproofed details meeting adjoining building materials.
| Warranty | Min. 15 years warranty |
| Materials | Flat Lock/Shingle panels available in materials and colours as above. For aluminium, must be 3005 alloy with min. H42 temper. Only PVDF coated aluminium, with a primer and min. two layer paint is suitable for this application. |
| Installation | Recommended and approved installers only |
| Manufacture | CASA System’s state-of-the-art machinery has been specifically developed to work with non-ferrous precious metals. Our manufacturing facility has been purpose-built to roll form, fold, curve and pack materials in accordance with the requirements of these type of metals. Only metals formed in CASA System’s facility form part of the system to ensure full warranty. |
